TP industry (capacitive touch screen industry), product terminals are commonly used in business display, medical education, industrial control, tablet computer, LCD TV, vehicle touch, etc.

Customer product

TP industry (capacitive touch screen industry), product terminals are commonly used in business display, medical education, industrial control, tablet computer, LCD TV, vehicle touch, etc.

Euipment operation environment

In the thousand grade dust-free purification workshop, the personnel shall wear dust-free and anti-static suits in a constant temperature (20-25 ℃) and humidity (40-60%).

Production line specification

Machine function

It is used for capacitive touch screen printing, wire drying, automatic film feeding, CCD automatic fine positioning, printing and processing, and automatic film output.

Production line specifications

The whole six color capacitive touch screen printing production line intelligent factory is composed of eight areas and 42 processes according to the previous section: feeding - cleaning; Printing section 6: conveying - Printing - film arrangement - drying - Cleaning - conveying - film storage; Rear section: blanking is divided into eight areas.

Process specification

Capacitive touch screen (acid resistant / protective adhesive / silver medal circuit) printing process: film feeding - CCD automatic fine positioning - shuttle transmission - Printing - glass unloading

Structure process

6 sets of automatic screen printing machines; 6 tunnel drying furnaces; 3 glass cleaning machines; 4 steering conveyors; 6 sets of two speed conveyors; 8 tablet setters; 2 sets of tipping machine; 5 film storage machines. This production line realizes the printing processing and automatic production monitoring of the whole process of glass from the blank on-line, processing, quality control and finished product off-line.

Manual or automatic loading

Auto loading section：

Automatic feeding machine or manual horizontal loading of products

Washing

Glass washing area:

Glass surface clean

Direction change conveying

Direction change conveying area：

Single glass input becomes 90 degree right angle output, so that the conveying direction of the glass becomes short edge leading.

Fast/slow speed convey

Belt convey area:

Quickly extend the distance from previous glass from the next glass.

Production line advantage

The application planning and design of the whole plant production line are integrated, and the capacitive touch screen six color production line covers an area of 4705m ²， The production line equipment realizes eight functions of automatic feeding, cleaning, conveying, printing, drying, film storage, turning over and blanking. It has a high degree of automation, reduces labor costs and effectively improves production efficiency. Simplify manual operation and improve production efficiency and quality. The whole line realizes man-machine interaction and effectively ensures the product excellence rate. Industry initiative and leading consciousness.

Efficient production and processing

Significantly improve the glass printing speed, product flow speed and matching efficiency of each module of the product, so as to greatly improve the production efficiency

Effective cost control

Compared with traditional glass screen printing factories, the number of workers is less, the yield of product capacity is increased, and the operation cost is greatly reduced

Stable improvement of quality

The glass moves automatically in the printing production line, without stain and damage caused by personnel contact. At the same time, intelligent software is used to automatically select and adjust the best production process, so as to realize high-quality and high-efficiency continuous batch production

Product printing control

The continuous operation can combine glass printing products of similar specifications in different orders according to the optimal effect to achieve the best quality and efficiency

人员安全保障

自动化加工印刷模式不仅很大程度的减少作业人员与玻璃的接触，降低了员工受伤概率，而且避免了人工带来的各种误判、误操作。
